Digital Multimeter KEYSIGHT B2987B

DEVICE IS FOR:
The Keysight B2987B Digital Multimeter is a high resistance meter that reliably measures small currents with a resolution of 0.01 fA (0.01´10-15 A) and large resistances up to 10 PΩ (10´1015 Ω). It has a 4.3” color LCD display with a graphic user interface, which, in addition to numeric data, provides trend graphs and histogram data.Basic parameters:
Maximum current measurement range: 2 pA−20 mA with a resolution of 6½ digits
Load voltage: >20 μV in the lowest current range
Measures resistance: 10 pΩ (1016Ω)
Input impedance greater than 200 TΩ for measuring voltages up to 20 V
Universal USB 2.0 interface: LAN, GPIB, LXI Core
